KVL - Vertical high pressure ring section barrel pump

  • Q = 4 – 120 l/s
  • H = 12 – 350 m
  • p = 40 bar
  • t = 10 – 120 ºC
  • nmax = 1450 rpm
  • Katalog (.pdf)

KVL and KVLv pumps are adapted for the pumping of condensate, clean water and the water containing substantial amount of impurities. These pumps are adapted for water supply up to 105°C. Application of these pumps to hot water supply up to 130°C is also obtainable by the cooling of packings. Range of these pumps is suitable for particularly heavy suction conditions. Their vertical desing makes possible safety operation and a very little space is necessary for their assembly.
